Cash Machine

Our Automatic Cash Handling Machine efficiently accepts and dispenses banknotes and coins, ensuring secure and reliable transactions. It is suitable for self-service terminals, retail, and vending machines. Multiple models and flexible customization are available to meet your specific needs.

Machine Parameters

Core Parameters	NCM01S	NCM01	NCM01 PRO
Rejects counterfeit notes and coins	✓	✓	✓
Banknote number of the cashbox	400	1000	1000
Banknotes recycler capacity	40 notes, mixed	80 notes, mixed	680 notes (4×70), 400 replenish
Banknote validation speed	4 s/note	2 s/note	2 s/note
Banknote dispensing speed	4 notes/sec	3.2 notes/sec	1.5 sec (up to 10 notes)
Banknote dispensing speed	4 s/note	3.2 s/note	1.5 s (bundle up to 10)
Coin recycler capacity	1500 mixed	1500 mixed	1500 mixed
Coin number of the coinbox	450	450	1000
Coin validation speed	4 coins/s	4 coins/s	4 coins/s
Coin dispensing speed	12 coins/s	12 coins/s	12 coins/s
Refill Banknote box	✘	✘	400 mixed notes
Remote online debug	✔	✔	✔
Dimensions (cm)	42×42×63	42×41×63	42×41×67
Built-in PAYMENT SYSTEM	✓	✓	✓
Weight	34 KG	36.5 KG	50.8 KG

Running Mode

Mode	Description	Main Steps
Standalone	Operated directly via the machine's touch screen, suitable for cashier or self-service use.	The cashier inputs the payment amount on the touch screen, then inserts cash. The machine displays the real-time amount inserted. The machine determines whether change is needed and dispenses it accordingly. Once the full amount is received, the machine confirms the transaction. The transaction is completed. Optionally, a receipt can be printed.
REST API	Integrated with POS or other systems via REST API for automated cash handling.	The POS system or another system informs the machine of the transaction amount via REST API. The machine prompts the customer to insert cash and displays the real-time amount inserted on the screen. The machine determines whether change is needed and dispenses it accordingly. The POS system retrieves the transaction completion information via REST API. The transaction is completed.
Vending Machine	Used as a payment and dispensing module in vending machines.	Customer selects the desired product. Customer proceeds with the payment. The system prints a receipt.
